• Color Temperature：Cool White
• Emitting Color：Cool White
• LED Chips Brand：Epistar
• Certification：CCC, CE, RoHS, Atex
• Transport Package：Wooden or Paper Case
• Specification：IP65
• Trademark：Wantai
• Origin：Huainan City Anhui Province
• Production Capacity：50000 Pieces,Year

Basic Info.

Color Temperature Cool White Emitting Color Cool White LED Chips Brand Epistar Certification CCC, CE, RoHS, Atex Transport Package Wooden or Paper Case Specification IP65 Trademark Wantai Origin Huainan City Anhui Province Production Capacity 50000 Pieces/Year

Product Description

Underground mine roadway Explosion-Proof 127V LED mining lamp

Application

It is suitable for fixed continuous lighting in coal mine tunnels, metal mines, coal washing plants, high-speed and high-speed railway tunnels, chambers, etc. in the environment with methane, gas, coal dust or explosive gas, and is suitable for other lighting places with explosion-proof requirements

Features

1. The LED roadway light uses high-power and high-performance LED as the light source. Small size and low power consumption; the LED light source used can last up to 50,000 hours for continuous lighting, which is hundreds of times the life of incandescent lamps
2. The shell is made of aluminum alloy die-casting, with high strength; the surface is high-pressure electrostatic spray, corrosion-resistant. Lightweight structure;
3. Glass protection capacity is tempered high borosilicate, impact resistance, high strength
4. Wide range of working voltage and strong adaptability. The grid voltage can work normally within the range of 80V-260V, and there is no change in brightness, which can prevent the phenomenon of burning lamps due to voltage fluctuations in the mine.

Technical parameters


Explosion-proof mark	ExdIMb
Rated voltage	AC85-265V
Protection level	IP65
Anti-corrosion grade	WF2
Inlet thread	G3/4
Drop cable	φ10'-14
Operating temperature	-30°C-60°C
Package dimensions	460x275x405mm
Net weight	3.5kg J
Quantity	4 pcs/carton

Model	Type	Luminous flux	Power	Color temperatures	illuminance
DGS24/127L(A)	LED	2640lm	24w	6000-6500k	125LX
DGS30/127L(A)	LED	3300lm	30w	6000-6500k	130LX
DGS36/127L(A)	LED	3900lm	36w	6000-6500k	143 LX
DGS40/127L(A)	LED	4200lm	40w	6000-6500k	157LX
