LED Professional Lighting

Zoom 18X12W Waterproof 6in1 Outdoor LED PAR Light

Uplight Stage Equipment (Guangzhou) Co., Ltd.
  • Type:PAR18
  • Emitting Color:RGBWA+UV
  • Power:12W
  • Waterproof:Waterproof
  • IP Rating:IP66
  • Life:80000h

Base Info

  • Model NO.:UP-PF1812
  • Electric Current Type:AC
  • Input Voltage:AC100V-220V, 50,60Hz
  • Shell Material:Aluminium Alloy
  • LED Chips:CREE
  • Certification:CE, RoHS
  • Light Source:18PCS*12W CREE
  • LED Luminance:More Than 5, 000 Lux
  • Average Life:80000~100000 Hours
  • Color System:RGBWA UV 6in1
  • Color Effect:Uniform Color Washing Effect
  • Zoom:Linear Zooming
  • Lens:High Efficiency and Transmission Large Lens
  • Lens Angle:10 Degree-60 Degree
  • Transport Package:Carton,Flightcase
  • Specification:CE RoHS
  • Trademark:UPLIGHT
  • Origin:Guangzhou, China
  • HS Code:94054090
  • Production Capacity:300 PCS , Month

Description

Light source18pcs 12W RGBWAUV 6in1 led chips;LED luminance: More than 5,000 lux;Average life: 80000~100000 hours;LED Lamp powr supplyAdopt power factor correction PFC switching power supply, PF> 0.99, the efficiency of up to 90%, it's real green and environmental protection;LED drive modeAdopt static constant current drive mode with high precision and non-flicker (400HZ);Color system Purple (Ultraviolet), Amber, Red, Green, Blue, White 6in1 Color mixing system with color rainbow which is reaching high colour rendering index and  the most favorite color mixing way for lighting technician;Color effectUniform color washing effect with no colour shadows, rich saturated and more pastel lighting;ZoomLinear zooming;Lens18pcs high efficiency and transmission large lens;Emitting angle10°~60°;Waterproof gradeIP64;Strobe1~10 strobes/seconds;Dimmer0~100% linear dimmer;Control modeDMX512 signal 3-pins connection control, master-salve control, multiple connection in series control with self-programming mode, self-running mode, external control mode;Channel 11 Channel;Other functionDMX address can be adjusted; DMX address extension function; IP address extension function;Working temperature-15° C ~45° C;Shell materialAluminum alloy;ApplicationLighting for TV studio, theater, opera house, auditorium, stage, T-stage, concerts, and vocal concert, DJ effect, disco effect, club effect, party effect etc;Packing size300×300×380mm;Gross weight10kg
10 channlesFunction
CH 1Dimming
CH 2RED
CH 3GREEN
CH 4BLUE
CH 5WHITE
CH 6ULTRAVIOLET
CH 7AMBER
CH 8Strobe
CH 9Speed
CH 10Auto Running & Sound Control
CH 11Zoom


Production Line:
Zoom 18X12W Waterproof 6in1 Outdoor LED PAR Light
