4FT LED Waterproof Fixture with Clips for Parking Lot
NINGBO SUNNYLUX IMPORT & EXPORT CO., LTD.- Type:Anti-glare Tri-proof Light
- Feature:Anti-corrosion, Dust-Proof, Waterproof
Base Info
- Model NO.:SLWP-FI81-212E
- Light Body Material:Plastic
- IP Rating:IP65
- Housing Color:White
- Lifespan:10000 Hours-50000 Hours
- Warranty:3 Years
- Certification:Ce, CQC, EMC, FCC, GS, RoHS, SAA, UL
- with Light Source:with Light Source
- Lamp Body Material:PC
- Beam Angle:120
- Voltage:100-240V
- Size(mm):See The Description
- Power:9 18 24 18 36 48
- Input Voltage:100-130, 220-240V 50,60Hz
- Diffuser Material:PC+ Milk White
- LED Model:SMD 2835
- Luminous Flux:90lm,W
- Transport Package:Carton Box
- Specification:CE, RoHs
- Trademark:Sunnylux
- Origin:Ningbo China
- HS Code:9405409000
- Production Capacity:50000PCS,Month
Description
Basic Info.
Model NO. SLWP-FI81-212E Light Body Material Plastic IP Rating IP65 Housing Color White Lifespan 10000 Hours-50000 Hours Warranty 3 Years Certification Ce, CQC, EMC, FCC, GS, RoHS, SAA, UL with Light Source with Light Source Lamp Body Material PC Beam Angle 120 Voltage 100-240V Size(mm) See The Description Power 9 18 24 18 36 48 Input Voltage 100-130, 220-240V 50/60Hz Diffuser Material PC+ Milk White LED Model SMD 2835 Luminous Flux 90lm/W Transport Package Carton Box Specification CE, RoHs Trademark Sunnylux Origin Ningbo China HS Code 9405409000 Production Capacity 50000PCS/MonthProduct Description
LED Waterproof Light LED Triproof Lighting IP65 CE ULFeature
Item Type | LED Waterproof Light IP65 | LED Waterproof Light IP65 | LED Waterproof Light IP65 | LED Waterproof Light IP65 | LED Waterproof Light IP65 | LED Waterproof Light IP65 |
Model Number | SLWP FI81E-106 | SLWP FI81E-112 | SLWP FI81E-115 | SLWP FI81E-206 | SLWP FI81E-212 | SLWP FI81E-215 |
Input Voltage | AC220~240V ± 10 % ; 50/60HZ | AC220~240V ± 10 % ; 50/60HZ | AC220~240V ± 10 % ; 50/60HZ | AC220~240V ± 10 % ; 50/60HZ | AC220~240V ± 10 % ; 50/60HZ | AC220~240V ± 10 % ; 50/60HZ |
Input Power | 9W | 18W | 24W | 2X9W | 2X18W | 2X24W |
LED | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 | SMD 2835 |
Luminous Flux | 830LM | 1660LM | 2210LM | 1660LM | 3360LM | 4200LM |
LED Qty | 48 | 96 | 120 | 96 | 192 | 240 |
Protection Level | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
Safety Level | II Type | II Type | II Type | II Type | II Type | II Type |
Temperature | -20 °C ~+50 °C | -20 °C ~+50 °C | -20 °C ~+50 °C | -20 °C ~+50 °C | -20 °C ~+50 °C | -20 °C ~+50 °C |
Size/mm (L*W*H-A) | 653*85*87 -416 | 1263*85*87 -838 | 1863*85*87 -1036 | 653*130*87 -416 | 1263*130*87 -838 | 1563*130*87 -1036 |
Packing size/mm | 680*375*300 | 1290*286*300 | 1590*286*300 | 680*416*300 | 1290*416*203 | 1590*416*203 |
2)The"A" size means the installation dimension.
1. Item Type: SLWP-FE01
2. LED Light Source: SMD2835
3. Input Voltage(V): 220-240
4. Lamp Power(W): 9 18 24 18 36 48
5. Lamp Luminous Efficiency(lm/w): >80
6. CRI (Ra>): 80
7. Color Temperature(CCT): 2700-6500K
8. Working Life time(Hour): 50000
9. Lamp Body Material: PC base + PC diffuser
10. IP Rating: IP65
11. Certification: CE, ROHS, UL
12. Warranty(years): 2
Advantage:
-LED: International first-class quality LED light source with a variety of color temperature for choice.
- Lamp body: Injection moulded with strengthening ribs, opaque UV stabilized
PC material, sealing strip in natural silicone rubber.
- Clips: with PC clips.
- Lamp cover: Injection moulded, high impact resistant PC material with light
diffusing agent which could shed soft light. Light transmittance ≥85%.
- Reflector: Metal.
Application:
Can be applied in wet interior, dusty place and outdoor places, such as
factory, warehouse, cold store, car parking, pharmaceutical&food industry,
tunnel, bathroom, etc.
Packaging & Delivery
Packaging Detail: 1pcs in one box 6pcs in one carton
Delivery Detail: 10-15 work days for sample, 25-30 work days for 1000 pieces.
Term of Trade:
FOB, CFR, CIF could be negotiation,
Certification:
CCC, CE, CQC, FCC, GS, RoHS, SAA, UL
