• Model NO.：TBD-GC-506L-8B6
• Color Temperature：Red ,Blue,Amber,White,Green,Purple Available
• IP Rating：IP65
• Operation Mode：Maintained
• Battery Type：Lead-acid
• Emitting Color：Red ,Blue,Amber,White,Green,Purple Available
• Material：Aluminum
• Certification：CE, RoHS, ISO
• Size：1000*150*105 Mm
• Chassis Material：Aluminum
• Light Source：1W or 0.5W LED
• Port：Ningbo,Shanghai,Guangzhou
• Delivery：7-35 Days
• Mini Order Quantity：1PC
• Transport Package：Cartons.
• Specification：CE, RoHS, ISO
• Trademark：HAIAN
• Origin：Zhejiang, China(Mainland)
• HS Code：8512209000
• Production Capacity：5000PCS,Month

Basic Info.

Model NO. TBD-GC-506L-8B6 Color Temperature Red ,Blue,Amber,White,Green,Purple Available IP Rating IP65 Operation Mode Maintained Battery Type Lead-acid Emitting Color Red ,Blue,Amber,White,Green,Purple Available Material Aluminum Certification CE, RoHS, ISO Size 1000*150*105 Mm Chassis Material Aluminum Light Source 1W or 0.5W LED Port Ningbo/Shanghai/Guangzhou Delivery 7-35 Days Mini Order Quantity 1PC Transport Package Cartons. Specification CE, RoHS, ISO Trademark HAIAN Origin Zhejiang, China(Mainland) HS Code 8512209000 Production Capacity 5000PCS/Month

Product Description

High brigtness slim emergency lightbar for ambluance , trucks and special vehicls




*DC 12 or 24V.
*0.5w or 1 w leds, 6 leds/module, 16 modules; 3 leds/module, 2 modules.
*Clear liner lens.
*Silver aluminum case.
*58K controller.
*21 flash patterns.
*Amber color leds, with white color leds as work lights and alley lights.
*Red, blue, amber, white color leds available. Green, purple for special orders.
*4 mtr cable, screws, brackets and hooks included.

The 506 series break out a narrow slim light bar body, that makes it a special design compaired with other emergency big light bars. Quicky becoming one of the more popular options on the market today. The 506 series have taken public safety by storm. Packed full of xtreme Tir LED modules for maximum wide angle output the diode count leaves competitors in the dust. An extruded aluminum base provides rigid support and shock absorption without sagging / benging, while the low profile design ruduce wind resistance. Compare this with other lightbars and you'll see that it is in a class by itself.
Long length design makes it suitable to instal on top of big fire and EMS trucks.



Item No	TBG-GC-506L-8B6
Voltage	DC 12V or 24V
Product Description	1w or 0.5w led lights, 6pcs/module,16 modules ; 3pcs/module , 2 modules
Led Color	red/blue/amber/white/green
Material	Clear PC Lens & Aluminum Case
Operating Temperature	-40 to 55(centigrade)
Cable	4 meter of cable with controller
Product Size	100*15*10.5cm
Carton Size/G.W.	1pc/ctn,106*22*14 cm,
Installation Method	Fixed by brackets & hooks
Remarks	Waterproof & Dustproof
