• Model NO.：LCD-CES-Jxxx
• Color Temperature：3000K 4000K 6500K
• Emitting Color：Red
• LED Chips Brand：Nichia
• Certification：CCC, CE, CQC, C-tick, EMC, Energy Star, ETL, FCC, FDA, GOST, GS, LVD, PSE, REACH, RoHS, SAA, SASO, UL, VDE, TUV Atex Iecex UL844
• Transport Package：Carton Box
• Specification：200x200x147mm
• Trademark：LCD brand
• Origin：Shenzhen City, China
• HS Code：9405409000
• Production Capacity：50000PCS , Year

CERTIFICATIONSLCD-CES-J series is a hazardous location LED lighting fixture Class I Division 2,
Groups A,B,C and D; Group II, Zone 1 & Zone 2; Zone 21 & 22.HOUSING BODYAluminum alloy ADC12LENS4mm thick tempered glass & PC reflector 25º 60º 90º 120º
+95% light transmission.
Shock and vibrations resistant.PERFORMANCE2600 to 24,050+ lumens
Up to 135 lm/w.
From 20W up to 185W.
L70 (hrs) rated > 65,000.IP67 & IP68 RATEDDust tight and protected against the effects of immersion in water to
depth between 15 cm and 1 meter.
0-10V dimming standard.
Ideal for heavy industry, mining, refineries, chemical industry, coastal
marine facilities and corrosive applications.MOUNTINGSurface/wall mount standard (adjustable mount bracket included).
Pendant kit optional.OPERATING TEMPERATUREFrom -40°F up to 122°F (-40°C to 50°C).DIMMING0-10V dimming standard , DALI, Triac





Technical Specifications

Certification
ATEX Rating: ATEX and IEC Ex rated for Gas and Dust
Hazardous Area rating: Zone 1 - Gas and Dust


Certificates:
UL, including C1D2

Gas: II 2 GD  Ex e mb op is IIC T* Gb
Ta= Up to -30°C to +50°C (-20°C to +46°C for emergency variants)
Dust:II 2D  Ex tb op is IIIC T* Db
Ta= Up to -30°C to +50°C (-20°C to +46°C for emergency variants)
IP67 & IP68



Electrical
Input:
100-277VAC, 50/60Hz  only
Low voltage: 18-48V AC and 18-32V DC
Extra low voltage: 12V AC/DC
Power:
20W to 185W standard
Termination

Incoming terminal block suitable for
looping 4 core 4mm² cable
Power Factor:

>0.95
Cable Entries:

4xM20 as standard (other entries
available upon request), dispatched
complete with three ATEX/IEC Ex
approved blanking plug



Optical / Photometric Specs
Beam Patterns-symmetric : 25°x 25° or 60°x 60° or 90°x 90° or 120°x 120°
(10 x 10 option can be upgraded to LCD-CESP Technology)
Lumen output on mains: 2,600 lm - 24,050 lm
LED type: Bridgelux or LUMILEDs SMD3030 LEDs chip
Number of LEDs: 36 / 108 / 192
CRI 75+
Colour Temperature: 3,000K 4,000K 6,000K

25º



60º



90º



120º





Mechanical/Environmental
Burning position: Universal
IP rating: IP67 & IP68
Temperature range: -30°C to +50°C (-20°C to +46°C for emergency variants)
Weight: Please contact LCD-CESP for copy
Enclosure: Marine grade aluminium epoxy powder coated, toughened glass, all external
fasteners and brackets are marine grade stainless steel
Unit Colour: grey , yellow, orange
Installation instructions: Please contact LCD-CESP for copy
Dimensions: Please contact LCD-CESP for copy
Mounting: Comes complete with stainless steel brackets(as shown on below )
Other options available

Model No.           Power(W)      Lumens(lm)      Color temperature                     Input Voltage     Current      Weight(kg)        Dimensions (mm)

LCD-CES-J20       20W               1300              3000k / 4000k / 6500K              85 ~ 265VAC         0.12A        4.0Kg                    200x200x147
LCD-CES-J30       30W               2600              3000k / 4000k / 6500K              85 ~ 265VAC         0.12A        4.0Kg                    200x200x147
LCD-CES-J40       40W               3900              3000k / 4000k / 6500K              85 ~ 265VAC         0.12A        4.0Kg                    200x200x147
LCD-CES-J60       60W               6500              3000k / 4000k / 6500K              85 ~ 265VAC         0.12A        7.5Kg                    300x300x165
LCD-CES-J80       80W              10400             3000k / 4000k / 6500K              85 ~ 265VAC         0.12A        7.5Kg                    300x300x165
LCD-CES-J100    100W             13000             3000k / 4000k / 6500K              85 ~ 265VAC         0.12A        7.5Kg                    300x300x165
LCD-CES-J120    120W             19500             3000k / 4000k / 6500K              85 ~ 265VAC         0.12A        10.5Kg                  400x400x169
LCD-CES-J150    150W             26000             3000k / 4000k / 6500K              85 ~ 265VAC         0.12A        10.5Kg                  400x400x169
LCD-CES-J185    185W             39000             3000k / 4000k / 6500K              85 ~ 265VAC         0.12A        10.5Kg                  400x400x169



SUITABLE FOR: Mining Sites, Heavy Industrials, Storage Facility, Paper mills, Wastewater Treatment Plants, Loading Docks, Platforms, Shipyards, Chemical Processing Facility, Petrochemical Processing Facility. The Flood light Series LED Luminaires are designed for installations where moisture, dirt, dust, corrosion and vibration may be present, or NEMA 3 and 4X areas where wind, water, snow or high ambient can be expected. They can be used in locations made hazard-ous by the presence of flammable vapors or gases or combustible dusts as defined by the NEC and IEC and Atex.CES-J Series are ideal for retrofit of existing HPS/MH and offer higher efficacy for increased energy savings, lower maintenance costs and shorter paybacks.

Best-in-class system efficacy - Up to 130 Lm / W
Universal Voltage: AC 100~277V / 347~480V (50/60Hz)
Instant illumination and restrike - no warm-up time required
Wide ambient temp. range from - 40 C to + 60 C ( -40 F ~ + 140 F)
Safe and reliable heat transfer - Offering a T-rating of T6 ( CI D1 )
Shock-and vibration-resistant - Durable LEDs with solder-less board connection Copper-free aluminum body and frame -corrosion resistant
All exposed fasteners with quality stainless steel
High Temperature silicone gasketing
Thermal shock and impact resistant glass lens
Harsh & Hazardous Duty

Class I, Div. 2,  Group A,B,C,D
Class II, Div. 2, Groups F,G
Class III
Enclosed and gasketed
Wet Locations / Type 4X / IP 66
UL-1598/8750 for LED Lighting
UL-1598(A)
UL-844 and CSA C22.2 for Hazardous locations DLC 4.0 Premium


(1)DC available on special request
(2)Warm white available indent only
*AC Current rating at 85 ~ 265VAC
**Black housing
***Marine coating
