• Model NO.：LCD-CES-EX-SC10-B1
• Voltage：90-260V
• Voltage Type：AC
• LED Type：SMD 5050
• Certification：CCC, CE, C-tick, EMC, Energy Star, ETL, FCC, LVD, PSE, RoHS, SAA, SASO, UL, Atex Iecex
• Transport Package：Carton Box
• Specification：100x100x538mm
• Trademark：LCD brand
• Origin：Shenzhen City, China
• HS Code：9405409000
• Production Capacity：50000PCS , Year

Basic Info.

Model NO. LCD-CES-EX-SC10-B1 Voltage 90-260V Voltage Type AC LED Type SMD 5050 Certification CCC, CE, C-tick, EMC, Energy Star, ETL, FCC, LVD, PSE, RoHS, SAA, SASO, UL, Atex Iecex Transport Package Carton Box Specification 100x100x538mm Trademark LCD brand Origin Shenzhen City, China HS Code 9405409000 Production Capacity 50000PCS / Year

Product Description

Product Overview

The ATEX LED Inspection Leadlamp LCD-CES-EX-SC10-B1 is a cable-powered,versatile and lightweight handheld light with impressive LED light output, making it ideal for inspection and work activities in hazardous areas. The LCD-CES-EX-SC10-B1 is CE marked to the ATEX Directive and IECEx certified safe for use in Zone 1 potentially explosive gas atmospheres, where a T4 temperature class permits, and Zone 21 potentially explosive dust atmospheres, with a maximum surface temperature of 80°C, as well as Group I mining applications.

The high power LED 'fitted for life' light source produces a forward facing high efficiency output of up to 470 lumens by emitting an exceptional,even, ultra-wide angle light; minimising shadows and enhancing visibility to provide optimum illumination for localised, close proximity work.

Lightweight, compact and ergonomically friendly, the Inspection Leadlamp is designed for handheld use, with an "easy-grip" handle for user comfort. With a flexible 360° swivel hook, the LCD-CES-EX-SC10-B1 can be suspended for hands-free use, and magnet mounting accessories are also available.

The unit is extremely robust and durable with impact resistant anti-static enclosure, IP66 rated, and scratch and chemical resistant temper glass lens, to withstand the rigours of heavy industrial use. Further protection is possible by fitting a stainless steel cage guard for enhanced mechanical protection, fully certified and ideal for use in the most demanding conditions.

The Leadlamp is available in three voltage input ranges: high 90-264VAC for general applications, and low 20-54VAC/12-24VDC and extra low 9-16VAC/DC for use in confined space applications, such as metal tanks.

Features & Benefits
Ideal for handheld inspection and work activities in a hazardous area ATEX and IECEx approved for Zone 1 and 21 explosive gas and dust atmospheres 3000 lumen high power 'fitted for life' LED light source High quality, even, ultra-wide angle LED light, reduces shadows and enhances visibility Large diffused light source minimises eye discomfort when viewed directly Lightweight and compact for handheld use Flexible integrated hook for suspension in the work area Robust and highly durable enclosure to withstand heavy industrial use Wide voltage range models Fitted with 10m HOFR cable as standard IP66 rated for use in the harshest environments
Group I mining approval Mounting and protection accessories available.
