• Model NO.：LCD-SH3305, ND8800-XXXX
• Color Temperature：3000K 4000K 6500K
• Emitting Color：Warm White, Daylight, Cool White
• LED Chips Brand：Lumileds , CREE, , Osram
• Certification：CCC, CE, C-tick, EMC, Energy Star, ETL, FCC, LVD, PSE, RoHS, SAA, UL, Iecex, Atex, UL844, TUV
• Transport Package：Carton Box
• Trademark：LCD brand
• Origin：Shenzhen City, China
• HS Code：9405409000
• Production Capacity：50000PCS , Year

Basic Info.

Model NO. LCD-SH3305/ ND8800-XXXX Color Temperature 3000K 4000K 6500K Emitting Color Warm White, Daylight, Cool White LED Chips Brand Lumileds , CREE, , Osram Certification CCC, CE, C-tick, EMC, Energy Star, ETL, FCC, LVD, PSE, RoHS, SAA, UL, Iecex, Atex, UL844, TUV Transport Package Carton Box Trademark LCD brand Origin Shenzhen City, China HS Code 9405409000 Production Capacity 50000PCS / Year

Product Description

IP66 Install Jelly Jar Explosion Proof Lighting Fixture Water-Proof and Dust-Proof IP66 20W 30W 35W 40W 50W 70W 80W 90W 100W 250W 300W 350W with Ex Junction Box and for IECEx UL844 Atex LED Flood Light


Hazardous location led light fixtures Zone 1 & Zone 2 and Zone 2 & Zone 22 for 20W 30W 35W 40W 50W 70W 80W 90W 100W 250W 300W 350W 400W and 500W.



Features:


• Long life time: Cree or Bridgelux LED chip and Patented design for heat dissipation.
• With Germany company Schuch tech. and experiences ensure 100% LED explosion proof lighting fixtures.
• Application: IP66 and can be used in oil fields,oil refineries,offshore oil platform,power plant,gas station,oil tanks, wharf, tunnel, pumping station,substation,the military base.
• Energy saving, beautiful design and different installation methods available.
• Sealed aluminum alloy body with anti-static and anti-corrosion power painting. The housing is of good quality ensuring water proof, flame proof, explosion proof and dust proof.
• Easy to install and several installation methods availbale.
• Advanced driver to ensure stabel performace and high safty.
• The led explosionmproof high bay lighting is of good lighting quality, clear lightight effect without a double image and energy saving.

Application:
Applied to oil fields, oil refineries, offshore oil platform, power plants, gas stations, oil tanks, wharf, tunnel, pumping station, substation, the military base, etc. Class I, Division 2 Hazardous Locations, Zone 1, Zone 21 and Zone 2, Zone 22 and II A, II B, II C explosive gas atmosphere.


Specification:

Parameter	Value
Power Consumption	20W 30W 35W 40W 50W 70W 80W 90W 100W 250W 300W 350W 400W and 500W
Input Voltage	AC 95-305V or 12V
Frequency	50-60 Hz
Beam Angle	90° /110° /120°
Explosion-proof Grade	Zone 1, Zone 21 and Zone 2, Zone 22
Corrosion-proof Grade	WF2
IP Grade	IP66
Power Factor	> 0.95
Total Harmonic Current	< 15-20%
Lamp Efficiency(%)	≥ 85-90%
Color Temperature(K)	Warm white: 2700-4000K; Pure white: 5000-6500K
Junction Temperature(TJ))	< 75 ° C
Color Rendering Index(CRI)	Ra> 70
Light Effect	100-135lm/W
Ambient Environment	Temperature: -30° C~50° C; Humidity: 10-90%RH(25° C)
Storage Temperature	-40° C-75° C
Lifespan	> 100,000Hs
Material	Aluminum Alloy
Installation Height	4~10m(flood light)/10~30m(project light)
Dimension(mm)	0.6 /
Net Weight	6 to 21Kg
Certificate	IECEx  Atex  UL844

Examples of mounting
