• Model NO.：LED 114H
• Electric Current Type：AC
• Input Voltage：220V
• Diffuser：Tempered Glass
• Shell Material：Aluminium Alloy
• LED Chips：CREE
• Certification：CE, RoHS, EMC, LVD
• Color：Rgbwauv 6-in-1
• Transport Package：Carton,Flycase
• Specification：Dimensions: 30*30*19cm Weight: 3.50kg
• Trademark：MSLighting
• Origin：Guangzhou, China
• HS Code：94054090
• Production Capacity：500PCS,Week

Specification:ModelLED 114H (9*18W RGBWAUV 6-IN-1 MULTI-CHIP LED)DMX Channel9CH/6CHControl panelDigital 4 characters alphanumericHousing ColorBlackOperating voltage100-230V ACControl ModesDirect DMX 512, Master/slave. Stand alone. Sound ActivityConnector3-PinXLR (In and Out)NO. of LED9*18W RGBWAUV 6-IN-1 MULTI-CHIP LED LAMPLED Life Time80000-100, 000 hoursBeam Angle25° /30°Power Consumption180WLight Projecting Distance5-50MIP RatingIndoorOperating Temperature-20° c-+45° cPacking Dimension30*30*19cm/ 64*31*62cm (6pcs)Gross Weight3.50KGS /18.00kg(6pcs)Compatibility:1. Color Range: 16.7 million  additive  RGBWA  colors; continuously  variable  intensity (256× 256× 256=16777216)2. Dimming 0-100%with regulated constant color control3. Strobe: 10 Flashed per second (any color)4. Function: it is max mix color, color change, flash, speed/luminance the adjustable5.9channel Mode and 6channel Mode would change each other in every light6.9CH Mode DMX ValueCH 1_General dimmer    (1-255, from dart to light)CH 2_Red                  (1-255, Dimmer, from dart to light)CH 3_Green                (1-255, Dimmer, from dart to light)CH 4_Blue                  (1-255, Dimmer, from dart to light)CH 5_White                (1-255, Dimmer, from dart to light)CH 6_AMBER              (1-255, Dimmer, from dart to light)CH 7_UV                   (1-255, Dimmer, from dart to light)CH 8_Strobe & Color change/ color gradual change openCH 9_Strobe & Color change& color gradual change' s speed adjustment (1-255, Speed adjustment, from slow to fast)7.6CH Mode DMX ValueCH 1_Red                   (1-255, Dimmer, from dart to light)CH 2_Green                 (1-255, Dimmer, from dart to light)CH 3_Blue                   (1-255, Dimmer, from dart to light)CH 4_White/Amber          (1-255, Dimmer, from dart to light)CH 5_AMBER                (1-255, Dimmer, from dart to light)CH 6_UV                     (1-255, Dimmer, from dart to light)8. Control modes0: sound activity mode1. DMX control mode2. Adjusting the color manual3. Adjusting the brightness manual4. Adjusting the strobe manual5. Adjusting the strobe speed manual6. Master-slave control mode, as the master7. Sound activity synchronization mode8. Adjustingcolor' s gradual change manual9. Adjustinggradual change' s speed
