• Length：2FT,4FT,5FT
• Width：Single,Double T8
• Transport Package：Carton
• Specification：T8,T5 LED Tube LIGHTING FITTING
• Trademark：longlux
• Origin：China
• Production Capacity：1000000

Basic Info.

Length 2FT/4FT/5FT Width Single/Double T8 Transport Package Carton Specification T8/T5 LED Tube LIGHTING FITTING Trademark longlux Origin China Production Capacity 1000000

Product Description

Feature

MATERIAL / FINISH

COLD ROLLED STEEL BASE
PLASTIC POWDER SPRAY SURFACE
PC T8/T5 LAMPHOLDER
LED WIRE CONNECTION
BROWN INNER BOX + BROWN MASTER CARTON
COMPLETE WITH T8/T5 LED GLASS TUBE

SPECIFICATION

INPUT POWER 220-240VAC 50/60Hz
ENERGY SAVING > 75%
50,000 HOURS AVERAGE LIFE
TOTAL HARMONIC DISTORTION (THD) < 7%
POWER FACTOR (P.F.) > 0.95
COLOUR RENDERING INDEX (CRI Ra) > 80
UV AND IR FREE        LOW HEAT RADIATION
NO STROBE OR FLICKERING EFFECT
MICRO-WAVE SENSOR FUNCTION AVAILABLE
EMERGENCY LIGHTING FUNCTION AVAILABLE

ORDERING GUIDE

MODELNUMBER	NUMBEROFLEDGLASSTUBE	SIZE
LLX-Fitting-118	1xT8 600mm / 1xT5 549mm	621(L) x 50(W) x 73(H) mm
LLX-Fitting-218	2xT8 600mm / 2xT5 549mm	621(L) x 102(W) x 74(H) mm
LLX-Fitting-136	1xT8 1200mm / 1xT5 1149mm	1229(L) x 50(W) x 73(H) mm
LLX-Fitting-236	2XT8 1200mm / 2xT5 1149mm	1229(L) x 102(W) x 74(H) mm
LLX-Fitting-158	1xT8 1500mm / 1xT5 1449mm	1529(L) x 50(W) x 73(H) mm
LLX-Fitting-258	2xT8 1500mm / 2xT5 1449mm	1529(L) x 102(W) x 74(H) mm
