12*3in1 RGB Tricolor + 6UV LED Wall Washer Light /LED PAR 64 Waterproof IP 65
Guangzhou MS Lighting Co., Ltd.(China)- Type:PAR64
- Emitting Color:Full Range
- Power:50W
- Waterproof:Waterproof
- IP Rating:IP65
- Life:80000h
Base Info
- Model NO.:LED 1005IIV
- Electric Current Type:AC
- Input Voltage:90-245V
- Diffuser:Tempered Glass
- Shell Material:Aluminium Alloy
- LED Chips:CREE
- Certification:CE, EMC, LVD
- Outdoor Using:IP 65
- Channels:7CH,4CH
- Lamp:12*3in1 RGB Tricolor + 6UV LED
- Transport Package:Carton,Flycase
- Specification:Packing Size: 27*27*37cm Weight: 5.0kg
- Trademark:MSLighting
- Origin:Guangzhou, China
- HS Code:94054090
- Production Capacity:500PCS,Week
Description
ModelLED 1005IIV (12*3in1 RGB Tricolor+6UV) Housing Material Aluminum Housing Color Black Aperture Cover PMMA Operating voltage 90-130V AC / 176-254V AC Power Switch Power Supply LED current 1400mA Control Modes Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization DMX Channel 7CH/4CH Control panel Digital 4 characters alphanumeric Connector 3-PinXLR (In and Out) NO. of LED 12*3in1 RGB Tricolor + 6UV LED LED Life Time 80000-100, 000 hours Beam Angle 25° /30° /45° /60° Power Consumption 70W Light Projecting Distance 5-230M IP Rating INDOOR, Outdoor, Waterproof, IP 65 Operating Temperature -20º C+45º C Dimensions 27*27*37(cm) Weight 4.5 (kg) Packing Dimension 27*27*37(cm) Gross Weight 4.8(Kg) Compatibility: 1. Color Range: 16.7 million additive RGBW colors; continuously variable intensity (256× 256× 256=16777216) 2. Dimming 0-100%with regulated constant color control 3. Strobe: 10 Flashed per second (any color) 4. Function: it is max mix color, color change, color' s gradual change, flash, speed/luminance the adjustable, and save function 5.7channel Mode and 4channel Mode would change each other in every light 6.7CH Mode DMX Value CH 1_ General dimmer (1-255, from dart to light) CH 2_ Red (1-255, Dimmer, from dart to light) CH 3_ Green (1-255, Dimmer, from dart to light) CH 4_ Blue (1-255, Dimmer, from dart to light) CH 5_ UV (1-255, Dimmer, from dart to light) CH 6_ Strobe & Color change/ color gradual change open CH 7_ Strobe & Color change& color gradual change' s speed adjustment (1-255, Speed adjustment, from slow to fast) 7.4CH Mode DMX Value CH 1_ Red (1-255, Dimmer, from dart to light) CH 2_ Green (1-255, Dimmer, from dart to light) CH 3_ Blue (1-255, Dimmer, from dart to light) CH 4_ UV (1-255, Dimmer, from dart to light) 8. Control modes 0: sound activity mode 1. DMX control mode 2. Adjusting the color manual 3. Adjusting the brightness manual 4. Adjusting the strobe manual 5. Adjusting the strobe speed manual 6. Master-slave control mode, as the master 7. Sound activity synchronization mode 8, Adjustingcolor' s gradual change manual 9. Adjustinggradual change' s speed. Each Package Included: 1 * LED LED 1005IIV LED par 64 Light with
Signal Cable: 3-PinXLR DMX In and Out + Water Power cable: Power Cable screw water proof connectors in and out (2ft cable) 1 * User Manual 1*Power cable: 3 Pin plug and screw water proof connector on other side. (2ft cable) 2* pyrocondensation. cannula (0.66ft = 20cm) 1* Waterproof connector' s cover for Power cable

Signal Cable: 3-PinXLR DMX In and Out + Water Power cable: Power Cable screw water proof connectors in and out (2ft cable)
