• Model NO.：LEDPAR 24-IP
• Shell Material：Aluminium Alloy
• Certification：CE, RoHS, EMC
• Application：Stage, Swimming Pool, Fountain, TV Studio, Outdoor Architectural Lighting
• Exterior Finish：Black
• Power Consumption：288W,240W,192W
• Transport Package：Carton , Flight Case
• Specification：324(D)*220(W)*262.4(H)mm
• Trademark：Color-imagination
• Origin：China
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. LEDPAR 24-IP Shell Material Aluminium Alloy Certification CE, RoHS, EMC Application Stage, Swimming Pool, Fountain, TV Studio, Outdoor Architectural Lighting Exterior Finish Black Power Consumption 288W/240W/192W Transport Package Carton / Flight Case Specification 324(D)*220(W)*262.4(H)mm Trademark Color-imagination Origin China Production Capacity 50000PCS/Year

Product Description

• Light Source

  Source:
  SI-135A LEDPAR 2418IP: 24*18W 6-in-1 LEDs (RGBWAUV)
  SI-135B LEDPAR 2415IP: 24*15W 5-in-1 LEDs (RGBWA)
  SI-135C LEDPAR 2410IP: 24*10W 4-in-1 LEDs (RGBW)
  Life Span: 50000H
  The life span may vary depending on several following factors but not limited to:
  Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming)



  Optics

  High efficiency optic system
  25°Beam angle (15°/45°optional)
  35°Field angle
  High output



  Color System

  RGBWAUV, RGBWA, RGBW
  Smooth and pure color mixing capability



  Strobe Effect

  0-25Hz high speed LED shutter/strobe effect with variable speed



  Dimming System

  0-100% Smooth linear LED dimming



  Control System

  10(6-in-1), 9 (5-in-1), 8 (4-in-1) DMX channels USITT DMX-512
  DMX512, master-slave, sound or auto operation
  Built-in programs
  Shielded input signal protection for stable signal without interference
  IP65 3-pin XLR cables IN/OUT



  Display System

  LED display
  4 Control buttons










• Cooling System

  Advanced cooling system integrated aluminum
  Over temperature protection management



  Power Supply

  Electronic supply with active PFC
  AC100-240V 50/60Hz
  IP65 Power cables IN&OUT
  288W/240W/192W Power consumption



  Housing

  Aluminum die-casting structure
  2 Hanging brackets
  Exterior finish: Black



  Installation

  1*Safety attachment point



  Operating Condition

  Operating positions: all (device on floor or fixed to a support)
  -25ºC to 45ºC ambient temperature
  IP65protection rating



  Compliance

  CE
  2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
  2014/30/EU - Electromagnetic Compatibility (EMC)
  2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)



  Weight

  N.W.: 8kg
  G.W.: 10kg



  Dimensions

  Product Dimensions: 324(D)*220(W)*262.4(H)mm
  Packing Dimensions: 280(D)*280(W)*370(H)mm
