• Model NO.：PAR56PC-252,351-R,Y,B,G,W,7CAC,7CRC
• Style：Modern Chinese Style
• Base Type：Screw Terminal
• Technics：Drawbench
• Voltage：12V
• Certification：CE, EMC
• LED Qty：108,144,252,333,144,441PCS
• Power：8,12,18,24,30,35W
• LED Chip：Epistar
• LED Color：Single Color,RGB
• Single Color：Red, Yellow, Blue, Green, Cool White, Warm White
• Warranty：One Year
• Cool White：6000-6500K
• Warm White：2700-3500K
• Neutral White：4000-4500K
• RGB Model：Inner, on,off, Remote, WiFi, DMX512, 2wire PLC
• Transport Package：Neutral Color Box with Foam
• Specification：CE, RoHS
• Trademark：Future Green or OEM
• Origin：China
• HS Code：9405409000
• Production Capacity：50, 000PC,Month

AC/DC 12VPCIP68PAR56PC-12W144pcsSMD3014/SMD283512W1200LMPAR56PC-18W252pcsSMD3014/SMD283518W1790LMPAR56PC-24W333pcsSMD3014/SMD283524W2135LMPAR56PC-30W144pcsSMD505030W2135LMPAR56PC-35W441pcsSMD3014/SMD283535W3070LM

Applications:
Be used for the decoration lighting under water or any water views, such as the swimming pool, eruptive fountain, scenic ponds, and so on.


Voltage details:
Single color: R/Y/B/G/CW/WW         (AC/DC12V)
RGB on/off controlled                   (AC12V)
DMX512 Controlled 4wires              (DC12v)
External controlled 4wires               (DC12V)
RGB 2wires PLC controlled             (AC12V)

Color Program details for RGB on/off controlled with memory (totally 16models:
1. White (Red+Green+Blue)
2.RED
3. Green
4.Blue
5. Skyblue(Green+blue)
6. Orange(Red+green)
7.Purple(red+blue)
8. static Blue color, Red gradually changing
9. static Green, Red gradually changing
10. static Blue, Green gradually changing
11. static white(Cool white)
12.G→B→GB→RG→RB→RGB→R Slow gradually changing in circulation
13.R→G→B→GB→RG→RB→RGB→RG→G→GB→B→RB→R gradually changing in circulation
14.R→G→B Jumpy changing from fast to Slow→R→(R→B→G) Jumpy changing from fast to Slow→(R→RB→RG→G→GB→RB→RG→GB)fast  gradually changing,then changed circulation
15,RG→G→GB→B→RB→R  Slow gradually changing in circulation
16. Program 14 +13 in Slow gradually changing in circulation

Features:
1. Adopt super-high bright LED as the light source and any single color is available, like red, green, blue, yellow, white and RGB colors. It is remote control.
2. Adopt thick glass as the body shell which is corrosion resistant and quick heat dispelling.
3. It is IP68
4. Longer life-span, above 50, 000 hours.
5. Low consumption, energy saving and environmental protecting.
6.The light color will be more easily to heat dissipation. So they has longer life-span than normal DIP-LED PAR56 underwater light.
7.The light is more bright-colored and more penetrating in water than normal DIP-LED PAR56 underwater light.

Cautions:
1. Work with AC12V, otherwise the light will be possibly damaged
2. This light should be installed not deeper than 50cm underwater
3. The power wire of the lights shall be joined with other power wire out of the water. Waterproof treatment should be done if the joint is in the water otherwise there is risk for water intrusion.
4. The light should be in the water for the test of remote function or other functions, and don't test it more than 3 minutes out of the water otherwise the light will be possibly damaged or caused disfunction. If the user is not available to test it in the water, then please shut off the light every 3 minutes to be cold for the new test


Our Advatage:
1. OEM &ODM acceptable
2. Overseas Agency is opened
3. Super Service we can reply you in 8hours
4. Provide full support in lighting solutions for customer request.
5. Small order qty availble, More quantity, more discount
6. Can collect the goods from your other supplier in China to save your shipping cost
7.16years experience in exporting and LED light field
8. Prompt reply

Contact: Ms. Eileen Liao
