• Model NO.：LEDPAR 3610FN
• Shell Material：Aluminium Alloy
• Certification：CE, RoHS, EMC
• Application：Stage, Swimming Pool, Fountain, Concerts, TV Studio, Architectural
• Exterior Finish：Black
• Power Consumption：400W
• Transport Package：Carton , Flight Case
• Specification：260(D)*315(W)*310(H)mm
• Trademark：Color-imagination
• Origin：China
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. LEDPAR 3610FN Shell Material Aluminium Alloy Certification CE, RoHS, EMC Application Stage, Swimming Pool, Fountain, Concerts, TV Studio, Architectural Exterior Finish Black Power Consumption 400W Transport Package Carton / Flight Case Specification 260(D)*315(W)*310(H)mm Trademark Color-imagination Origin China Production Capacity 50000PCS/Year

Product Description

• Light Source

  Source: 36*10W 4-in-1 LEDs,
  RGBW, low power consumption
  Flicker free operation
  for broadcast TV and FILM
  Life Span: 50000H
  The life span may vary depending on
  several following factors but not limited to:
  Environmental Conditions, Power/Voltage,
  Usage Patterns (On-Off Cycling), Control,
  and Dimming)



  Optics

  High efficiency optic system
  25°Beam angle (15°/45°optional)
  35°Field angle
  High output



  Color System

  RGBW
  Smooth and pure color mixing capability



  Strobe Effect

  0-25Hz high speed LED shutter/strobe
  effect with variable speed



  Dimming System

  0-100% Smooth linear LED dimming



  Control System

  4/6/8 DMX channels USITT DMX-512
  DMX512, master-slave,
  sound or auto operation
  Built-in programs
  Shielded input signal protection
  for stable signal without interference
  3-Pin XLR connectors IN/OUT



  Display System

  LED display
  4 Control buttons



  Cooling System

  Advanced cooling system integrated
  aluminum+fan system
  Over temperature protection management





• Power Supply



  Electronic supply with active PFC
  AC100-240V 50/60Hz
  Power cable IN
  400W Power consumption



  Housing

  Aluminum die-casting
  structure+metal pieces
  2 Hanging brackets
  Exterior finish: Black



  Installation

  1*Safety attachment point



  Operating Condition

  Operating positions:
  all (device on floor or fixed to a support)
  -25ºC to 45ºC ambient temperature
  IP20 protection rating



  Compliance

  CE
  2014/35/EU - Safety of electrical
  equipment supplied at low voltage (LVD)
  2014/30/EU -
  Electromagnetic Compatibility (EMC)
  2011/65/EU - Restriction of the use of
  certain hazardous substances (RoHS



  Weight

  N.W.: 6.2kg
  G.W.: 7.1kg



  Dimensions

  Product Dimensions:
  260(D)*315(W)*310(H)mm
  Packing Dimensions:
  330(D)*330(W)*380(H)mm
