• Model NO.：LED 3002,LED 3002A
• Electric Current Type：AC
• Input Voltage：220V
• Diffuser：Tempered Glass
• Shell Material：Aluminium Alloy
• LED Chips：CREE
• Certification：CE, EMC, LVD
• LED Spotllight：RGB,Wa
• Transport Package：Carton,Flycase
• Specification：310*270*480mm
• Trademark：MSLighting
• Origin：Guangzhou, China
• HS Code：94054090
• Production Capacity：500PCS,Week

Specification: ModelLED 3002 (48*1W)LED 3002A (48*3W)Housing MaterialAluminumAluminumHousing ColorBlack/WhiteBlack/WhiteAperture CoverAluminumAluminumOperating voltage90-254V AC90-130V AC / 176-254V ACLED current320mA680mAControl ModesDirect DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronizationDirect DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronizationDMX Channel6CH/3CH6CH/3CHControl panelDigital 4 characters alphanumericDigital 4 characters alphanumericConnector3-PinXLR (In and Out)3-PinXLR (In and Out)NO.of LED36*1W LEDS (12R/ 12B/ 12G)36*3W LEDS (12R/ 12B/ 12G)LED Life Time80000-100,000 hours80000-100,000 hoursBeam Angle25°/30°25°/30°Power Consumption60W150WLight Projecting Distance5-35M5-60MIP RatingIndoorIndoorOperating Temperature-20degree+45degree-20degree+45degreeCompatibility:1.  Color Range: 16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216)2. Dimming 0-100%with regulated constant color control3.Strobe: 10 Flashed per second (any color)4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable and Save function.5. 6channel Mode and 3channel Mode would change each other in every light6. 6CH Mode DMX ValueCH 1_General dimmer  (1-255, from dart to light)CH 2_Red              (1-255, Dimmer, from dart to light)CH 3_Green            (1-255, Dimmer,from dart to light)CH 4_Blue              (1-255, Dimmer ,from dart to light)CH 5_Strobe & Color change/ color gradual change openCH 6_Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)7. 3CH Mode DMX ValueCH 1_Red              (1-255, Dimmer,from dart to light)CH 2_Green        (1-255, Dimmer,from dart to light)CH 3_Blue              (1-255, Dimmer,from dart to light)8.Control modes0: sound activity mode1. DMX control mode2. Adjusting the color manual3. Adjusting the brightness manual4. Adjusting the strobe manual5. Adjusting the strobe speed manual6. Master-slave control mode, as the master7. Sound activity synchronization mode8. Adjusting color's gradual change manual9. Adjusting gradual change's speed.
