LED Vehicle Display Screen (CJXP-200003)
ZHEJIANG HUAAN SECURITY EQUIPMENT CO., LTD.- Usage：Fire Lights, Traffic lights
- Installation：Stand
- Color Temperature：Warm White
- IP Rating：IP65
- Operation Mode：Maintained
- Battery Type：Power Source
Base Info
- Model NO.：CJXP-200003
- Emitting Color：Red
- Material：Polycarbonate
- Certification：ISO
- Item No.：Cjxp-200003
- Brand：Haaq
- Color：Red
- Environment Temperature：-10-+60 Centigrade
- Voltage：DC 12V
- Power of Every Display Screen：35W
- Display Screen Size：256mm× 1024mm
- Resolution Ratio of Unit Area：3906 Dots,M²
- LED Wavelength：620~635
- LED Brightness：≥ 800mcd
- Transport Package：Export Standard Package
- Trademark：HAAQ
- Origin：Made in China
- Production Capacity：50 Set,Week
Description
| Environment temperature | -10-+60 centigrade |
| Voltage | DC 12V |
| Power of every display screen | 35W |
| Display screen size | 256mm× 1024mm |
| Resolution | 16(Y)× 64(X) |
| Resolution ratio of Unit area | 3906 dots/m² |
| Modules arrangement | 8(X)× 1(Y) |
| Modules measurement | 128mm(X)× 256mm(Y) |
| Screen body pixel | 1024× 3 dots |
| Whole brightness | >5000CD/ m² |
| LED chromaticity | Red(or amber) |
| LED wavelength | 620~635 |
| LED brightness | ≥ 800mcd |
| Angle of view | Horizontal:100° ; Vertical: 30° |
| Pixel interval | 16mm |
| Communication Way | Computer-- controller: RS232 Native COM port; Controller-- display screen: RS485 Native COM port |
| Whole contour dimension | 1270mm(length)× 565mm(width)× 545mm (height in the open status)260mm(height in the closed status) |
