• Model NO.：LED 1004I,LED 1004J
• Electric Current Type：AC
• Input Voltage：90-245V
• Diffuser：Tempered Glass
• Shell Material：Aluminium Alloy
• LED Chips：CREE
• Certification：CE
• LED Lamp：24,36*RGBW 4in1 Multi-Color LED Lamp
• Transport Package：Carton,Flycase
• Specification：50*27*27cm G. W.: 9KG
• Trademark：MSLighting
• Origin：Guangzhou, China
• HS Code：94054090
• Production Capacity：500PCS,Week

ModelLED 1004I (24*RGBW 4INI1)LED 1004J (36*RGBW 4INI1)Housing MaterialAluminumAluminumHousing ColorSilver/BlackSilver/BlackAperture CoverPMMAPMMAOperating voltage90-130V AC / 176-254V AC90-130V AC / 176-254V ACPower   Switch Power SupplySwitch Power SupplyLED current1400mA1400mAControl ModesDirect DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronizationDirect DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronizationDMX Channel7CH/4CH7CH/4CHControl panelDigital 4 characters alphanumericDigital 4 characters alphanumericConnector3-PinXLR (In and Out)3-PinXLR (In and Out)NO. of LED24*RGBW 4IN136*RGBW 4IN1LED Life Time80000-100, 000 hours80000-100, 000 hoursBeam Angle25° /30° /45° /60°25° /30° /45° /60°Power Consumption120W230WLight Projecting Distance5-180M5-230MIP RatingINDOORINDOOR,Operating Temperature-20º C+45º C-20º C+45º CDimensions48*26*26cm48*26*26cmWeight8.50kg8.50kgPacking Dimension50*27*27cm50*27*27cmGross Weight9.00kg9.00kgCompatibility:1.     Color Range: 16.7 million  additive  RGBW  colors; continuously  variable  intensity (256× 256× 256=16777216)2. Dimming 0-100%with regulated constant color control3. Strobe: 10 Flashed per second (any color)4. Function: it is max mix color, color change, color' s gradual change, flash, speed/luminance the adjustable, and save function5.7channel Mode and 4channel Mode would change each other in every light6.7CH Mode DMX ValueCH 1_ General dimmer       (1-255, from dart to light)CH 2_ Red                    (1-255, Dimmer, from dart to light)CH 3_ Green                  (1-255, Dimmer, from dart to light)CH 4_ Blue                   (1-255, Dimmer, from dart to light)CH 5_ White                  (1-255, Dimmer, from dart to light) CH 6_ Strobe & Color change/ color gradual change openCH 7 _ Strobe & Color change& color gradual change' s speed adjustment (1-255, Spee adjustment, from slow to fast)7.4CH Mode DMX ValueCH 1_ Red                    (1-255, Dimmer, from dart to light)CH 2_ Green                  (1-255, Dimmer, from dart to light)CH 3_ Blue                   (1-255, Dimmer, from dart to light)CH 4_ White                  (1-255, Dimmer, from dart to light) 8. Control modes0: sound activity mode1. DMX control mode2. Adjusting the color manual3. Adjusting the brightness manual4. Adjusting the strobe manual5. Adjusting the strobe speed manual6. Master-slave control mode, as the master7. Sound activity synchronization mode8, Adjustingcolor' s gradual change manual9. Adjustinggradual change' s speed.Each Package Included:1 *LED par 64 Light with
Signal Cable: 3-PinXLR DMX In and Out1 * User Manual
