• Model NO.：BPAR 1210F
• Shell Material：Aluminium Alloy
• Certification：CE, RoHS, EMC
• Application：Stage, Swimming Pool, Fountain, Live Concerts, Road Shows, DJ
• Exterior Finish：Black
• Power Consumption：120W
• Transport Package：Carton , Flight Case
• Specification：295(D)*235(W)*300(H)mm
• Trademark：Color-imagination
• Origin：China
• Production Capacity：50000PCS,Year

Basic Info.

Model NO. BPAR 1210F Shell Material Aluminium Alloy Certification CE, RoHS, EMC Application Stage, Swimming Pool, Fountain, Live Concerts, Road Shows, DJ Exterior Finish Black Power Consumption 120W Transport Package Carton / Flight Case Specification 295(D)*235(W)*300(H)mm Trademark Color-imagination Origin China Production Capacity 50000PCS/Year

Product Description

• Light Source

  Source: 12*10W 4-in-1 LEDs, RGBW
  Flicker free operation for broadcast TV and FILM
  Life Span: 50000H
  The life span may vary depending on several following factors but not limited to:
  Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling),
  Control, and Dimming)



  Optics

  High efficiency optic system
  25°Beam angle (15°/45°optional)
  35°Field angle
  1 4-leaf barn door system included to narrow projection field
  1 frost filter to enlarge field protection
  High output



  Color System

  RGBW
  Smooth and pure color mixing capability



  Strobe Effect

  0-25Hz LED shutter/strobe effect with variable speed



  Dimming System

  0-100% Smooth linear LED dimming



  Battery System

  Rechargeable secondary Li-ion battery built-in (auto charging once plugging in the power cable,
  20 fixtures linkable in daisy chain)
  Battery Life With Full Charge: 22 Hours (Single Color); 22 Hours (Sound Active);
  22 Hours (Fade Mode);
  6 Hours (Full On)
  Battery Charge Time: 4 Hours (3A)
  Battery Lifetime: Average Lifetime is 800 Charges
  (This depends on charging frequency)
  Battery charging status indicator available



  Control System

  6/8/10 DMX channels USITT DMX-512
  DMX512, master-slave, sound or auto operation
  RDM available (Remote Device Management)
  2.4G Wireless Solution system built-in for wireless operation
  Master/Slave available for wireless system
  Compatible with UC IR wireless remote
  (6 colors with dimming, 9 mixing color options,
  auto color mode, strobe mode, auto fading mode,
  sound mode, master dimming and speed, IR ON/OFF)
  4 Sound modes available
  4 Auto operation modes available
  2 Color modes available
  (customized color mode and static color mode)
  Built-in programs that could be called up via a DMX controller
  Shielded input signal protection for stable signal without interference
  IP65 3-pin XLR connectors IN/OUT





• Display System



  1.8" TFT LCD display
  4 Control buttons
  Display auto OFF time optional
  Display backlight color adjustable
  Display backlight brightness adjustable
  Fixture running time display available
  Fixture operation temperature display available



  Cooling System



  Advanced cooling system integrated aluminum
  Over temperature protection managemen



  Power Supply

  Electronic supply with active PFC
  AC100-240V 50/60Hz
  IP65 POWERCON IN&OUT
  IP65 Power switch available
  120W Power consumption



  Housing

  Aluminum die-casting structure
  Vent valve available for easy frost/steam cleaning
  2 Hanging brackets
  Exterior finish: Black



  Installation

  1*Safety attachment point



  Operating Condition

  Operating positions:
  all (device on floor or fixed to a support)
  -25ºC to 45ºC ambient temperature
  IP65protection rating



  Compliance

  CE
  2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
  2014/30/EU - Electromagnetic Compatibility (EMC)
  2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)



  Weight

  N.W.: 5.1kg
  G.W.: 6kg



  Dimensionsn

  Product Dimensions: 295(D)*235(W)*300(H)mm
  Packing Dimensions: 280(D)*280(W)*370(H)mm
