• Model NO.：LED 1011B,LED 1011E
• Electric Current Type：AC
• Input Voltage：220V
• Diffuser：Tempered Glass
• Shell Material：Aluminium Alloy
• LED Chips：CREE
• Certification：CE, EMC, LVD
• Outdoor Using：IP 65
• LEDs 1：90*3in1 Trip Color RGB LED
• LEDs 2：120*3in1 Trip Color RGB LED
• Transport Package：Carton,Flycase
• Specification：420*420*470 (mm) G. W.: 19KGS
• Trademark：MSLighting
• Origin：Guangzhou, China
• HS Code：94054090
• Production Capacity：500PCS,Week

Basic Info.

Model NO. LED 1011B/LED 1011E Electric Current Type AC Input Voltage 220V Diffuser Tempered Glass Shell Material Aluminium Alloy LED Chips CREE Certification CE, EMC, LVD Outdoor Using IP 65 LEDs 1 90*3in1 Trip Color RGB LED LEDs 2 120*3in1 Trip Color RGB LED Transport Package Carton/Flycase Specification 420*420*470 (mm) G. W.: 19KGS Trademark MSLighting Origin Guangzhou, China HS Code 94054090 Production Capacity 500PCS/Week

Product Description

This LED light adopts in 90/120*3IN1 RGB which is the most advanced lamp as light sources. It is new generation green high technology product. It projects long distance, big angle, and abundant colors. It brings people new vision sense, which makes people feel they are in a changeable color world.

The nice design is good for dispelling heat very well and long life. Project angle can be adjusted randomly. The base is with holes, which are facility for orientation and fitting.

It is widely used in stage show, casino, advertisement, outside wall of mansion etc. It is controlled by controller with DMX; The effect can be gradual change, jump change, color glitter, random change, and alternate gradual change and so on. Perfect cast light beam provides architecture designers and light designers abundant imagine space.

Item NO: LED 1011B
Light Source: 90*3IN1 Trip color RGB LED
LED current: 680mA
Power Consumption: 450W
Light Projecting Distance: 5-80M

Item NO: LED 1011E
Light Source: 120*3IN1 Trip color RGB LED
LED current: 680mA
Power Consumption: 550W
Light Projecting Distance: 5-80M

Specification:
Housing Material: Die-casting Aluminum
Housing Color: Black (White can choose)
Aperture Cover: PMMA
Operating voltage: 90-130V AC / 176-254V AC
Control Mode: Direct DMX 512, Master/slave. Stand alone.
Sound Activity, Sound activity synchronization
DMX Channel: 6CH/3CH (RGB)
Control panel: Digital 4 characters alphanumeric
Connector: 3-PinXLR (In and Out)
LED Life Time: 80000-100, 000 hours
Beam Angle: 60/250/300/450/600 /1200°
IP Rating: Outdoor, Waterproof, IP 65
Operating Temperature: -200C-+450C

Compatibility:
1. Color Range 16.7 million additive RGB/RGBW colors; Continuously variable intensity (256*256*256=16777216)
2. Dimming 0-100%with regulated constant color control
3. Strobe: 10 Flashed per second (any color)
4. Function: It is max mix color, color change, colors gradual change, flash, speed/luminance the adjustable, and save function
5. 6channel Mode and 3channel Mode would change each other in every light
6. 6CH Mode DMX Value
CH 1 General dimmer (1-255, from dart to light)
CH 2 Red (1-255, Dimmer, from dart to light)
CH 3 Green (1-255, Dimmer, from dart to light)
CH 4 Blue (1-255, Dimmer, from dart to light)
CH 5 Strobe & Color change/ color gradual change open
CH 6 Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)
7.3CH Mode DMX Value
CH 1 Red (1-255, Dimmer, from dart to light)
CH 2 Green (1-255, Dimmer, from dart to light)
CH 3 Blue (1-255, Dimmer, from dart to light)
8. Thermal:
Maximum ambient temperature: 400C
Maximum housing temperature: 600C
