• Model NO.：LEDPAR 24
• Electric Current Type：AC
• Input Voltage：220V
• Diffuser：Tempered Glass
• Shell Material：Aluminium Alloy
• LED Chips：CREE
• Certification：CE
• Application：Stage, Swimming Pool, Fountain
• Transport Package：Carton,Flight Case
• Specification：324(D)*220(W)*262.4(H)mm
• Trademark：Color imagination
• Origin：China
• Production Capacity：5000PCS,Years

Basic Info.

Model NO. LEDPAR 24 Electric Current Type AC Input Voltage 220V Diffuser Tempered Glass Shell Material Aluminium Alloy LED Chips CREE Certification CE Application Stage, Swimming Pool, Fountain Transport Package Carton/Flight Case Specification 324(D)*220(W)*262.4(H)mm Trademark Color imagination Origin China Production Capacity 5000PCS/Years

Product Description

Technical specifications

• Light Source

  Source:
  SI-077A LEDPAR 2418:
  24*18W 6-in-1 LEDs (RGBWAUV)
  SI-077B LEDPAR 2415:
  24*15W 5-in-1 LEDs (RGBWA)
  SI-077C LEDPAR 2410F:
  24*10W 4-in-1 LEDs (RGBW)
  Life Span: 50000H
  The life span may vary depending on
  several following factors but not limited to:
  Environmental Conditions, Power/Voltage,
  Usage Patterns (On-Off Cycling), Control,
  and Dimming)



  Optics

  High efficiency optic system
  25°Beam angle (15°/45°optional)
  35°Field angle
  High output



  Color System

  RGBWAUV, RGBWA, RGBW
  Smooth and pure color mixing capability



  Strobe Effect

  0-25Hz high speed LED shutter/strobe
  effect with variable speed



  Dimming System

  0-100% Smooth linear LED dimming



  Control System

  10(6-in-1), 9 (5-in-1), 8 (4-in-1) DMX
  channels USITT DMX-512
  DMX512, master-slave,
  sound or auto operation
  Built-in programs
  Shielded input signal protection
  for stable signal without interference
  3-pin XLR connectors IN/OUT



  Display System

  LED display
  4 Control buttons



• Cooling System

  Advanced cooling system
  integrated aluminum
  Over temperature protection management



  Power Supply

  Electronic supply with active PFC
  AC100-240V 50/60Hz
  Power cable IN
  288W/240W/192W Power consumption



  Housing

  Aluminum die-casting structure
  2 Hanging brackets
  Exterior finish: Black



  Installation

  1*Safety attachment point



  Operating Condition

  Operating positions:
  all (device on floor or fixed to a support)
  -25ºC to 45ºC ambient temperature
  IP20 protection rating



  Compliance

  CE
  2014/35/EU - Safety of electrical
  equipment supplied at low voltage (LVD)
  2014/30/EU -
  Electromagnetic Compatibility (EMC)
  2011/65/EU - Restriction of the use of
  certain hazardous substances (RoHS



  Weight

  N.W.: 2.3kg
  G.W.: 2.8kg



  Dimensions

  Product Dimensions:
  324(D)*220(W)*262.4(H)mm
  Packing Dimensions:
  260(D)*260(W)*370(H)mm
