Tri-Proof LED Light, Waterproof IP66 Stainless Steel Housing Linear LED Light for Tunnels
Cixi Yuanhui Lighting Electric Co., Ltd.- Application：Parking Lot
- Type：Efficient-Mirror Tri-proof Light
- Feature：Anti-corrosion, Dust-Proof, Waterproof, Tri-Proof
- Light Body Material：Stainless Steel
- Transport Package：Innerbox&Carton
- Specification：Product Size 670,1280,1590*110*65mm
Base Info
- Model NO.：YL12
- Trademark：Default is Yuanhui Can be customized
- Origin：Ningbo, China
- HS Code：9405409000
- Production Capacity：10000PCS,Month
Description
1.Technical Paramenters (Test Conditions:25ºC/55-%60%Humidity)Item Code YL12-25W-600 YL12-35W-1300 YL12-50W-1300 YL12-45W-1600 YL12-62W-1600 Power(W)+/-10% 25W 35W 50W 45W 62W Input Voltage/Frequency AC 220-240V 50/60Hz Installation Easy and quick to install under celling or on surface Housing/Diffuser 304 stainless steel housing,Tempered glass diffuser. Driver Osram / Philips / Tridonic / Chinese local brand LED Brand SMD2835 / SMD3030 CCT 2700-6500K (ANSI C78.377) CRI > 80 5000K/Opal Diffuser 3,500 lm 4,900 lm 7,000 lm 6,300 lm 8,680 lm Light Output(+/- 3%) Power factor PF>0.9 Beam Angel 90° / 120° IP Rating IP65 Warranty 5 Year Operating temp range -20 to +40 or -35 to +50 Clips Qty (pcs) 6 10 10 12 12 Product Size (mm) 670*110*65 1280*110*65 1590*110*65
