LED X-ray Film Illuminator, Observation Lamp with Ce (X-LEDIT)
Omni Well Industrial (Wuhan) Co., Ltd.- LED Resource：1 Blank
- Transport Package：Wooden Case
- Specification：CE, ISO13485, ISO9001
- Trademark：Keling
- Origin：Wuhan, China
Base Info
- Model NO.：X-LEDIT
- HS Code：9405409000
- Production Capacity：5000 PCS,Year
Description
Basic Info.
Model NO. X-LEDIT HS Code 9405409000 Production Capacity 5000 PCS/YearProduct Description
Features:With the function of automatic switching-on upon film-inserting
With the function of delayed switching-off after a film is removed
Install method: Wall-mounted type and bracket type(the bracket is an optional component)
| External dimensions(mm): | 460*520 |
| Film-viewing area(mm): | 360*440 |
| Backlight source type: | LED Color temperature: 9,300K |
| Service life: | 80,000 hours |
| Average brightness: | 300 cd/m2-4000 cd/m2 |
| Average illuminance: | 900 lux-13,000 lux |
| Brightness uniformity coefficient of viewing screen: | ≥90% |
| Appropriate films: | ordinary analog x-ray film |
| high-density digital x-ray film | |
| mammography medical film | |
| Power supply:v | oltage self-adaption built-in power supply |
| Voltage: | AC110V-240V |
| Power: | 35W±10% |
| Frequency: | 50/60Hz |
| Operating conditions: | The ambient illuminance in the room shall not exceed 100 lux |
| Dimension | 580*140*655mm |
| Package | 1 Wooden case |
| Gross Weight | 12kg |
