LED X-ray Film Illuminator, Film Viewer, Film Observation, Observation Lamp with CE (X-LEDIIIT)
Omni Well Industrial (Wuhan) Co., Ltd.- Emitting Color：White
- Certification：CE, EMC
- LED Resource：3 Blanks
- Transport Package：Wooden Case
- Specification：CE, ISO13485, ISO9001
- Trademark：Keling
Base Info
- Model NO.：X-LEDIIIT
- Origin：Wuhan, China
- HS Code：9405409000
- Production Capacity：5000 PCS,Year
Description
Basic Info.
Model NO. X-LEDIIIT Origin Wuhan, China HS Code 9405409000 Production Capacity 5000 PCS/YearProduct Description
Features:With the function of automatic switching-on upon film-inserting
With the function of delayed switching-off after a film is removed
Install method: Wall-mounted type and bracket type(the bracket is an optional component)
| External dimensions(mm): | 1180*520 |
| Film-viewing area(mm): | 1080*420 |
| Backlight source type: | LED Color temperature: 9,300K |
| Service life: | 80,000 hours |
| Average brightness: | 300 cd/m2-4000 cd/m2 |
| Average illuminance: | 900 lux-13,000 lux |
| Brightness uniformity coefficient of viewing screen: | ≥90% |
| Appropriate films: | Ordinary analog x-ray film High-density digital x-ray film Mammography medical film |
| Power supply:v | voltage self-adaption built-in power supply |
| Voltage: | AC110V-240V |
| Power: | 150W±10% |
| Frequency: | 50/60Hz |
| Operating conditions: | The ambient illuminance in the room shall not exceed 100 lux |
| Dimension(mm) | 1300*140*655 |
| Package | 1 Wooden case |
| Gross Weight | 23.5kg |
