LED Waterproof PAR 64 / LED Wall Washer Light LED Stage Light

Guangzhou MS Lighting Co., Ltd.(China)
  • Type：PAR64
  • Emitting Color：Full Range
  • Power：30W
  • Waterproof：Waterproof
  • IP Rating：IP65
  • Life：80000h

Base Info

  • Model NO.：LED 1005II,LED 1005III,LED 1005V
  • Electric Current Type：AC
  • Input Voltage：90-245V
  • Diffuser：Tempered Glass
  • Shell Material：Aluminium Alloy
  • LED Chips：CREE
  • Certification：CE, EMC, LVD
  • Color：RGB 3-in-1
  • Transport Package：Carton,Flycase
  • Specification：255*255*365mm
  • Trademark：MSLighting
  • Origin：Guangzhou, China
  • HS Code：94054090
  • Production Capacity：500PCS,Week

Description

LED 1005II (12*3IN1 RGB)LED 1005III (12*3W RGB)LED 1005V (18*3W RGB)Housing MaterialAluminumAluminumAluminumHousing ColorBlack/WhiteBlack/WhiteBlack/WhiteAperture CoverPMMAPMMAPMMAOperating voltage90-254V AC90-254V AC90-254V ACPower  Switch Power SupplySwitch Power SupplySwitch Power SupplyLED current680mA680mA680mAControl ModesDirect DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronizationDirect DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronizationDirect DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronizationDMX Channel6CH/3CH6CH/3CH6CH/3CHControl panelDigital 4 characters alphanumericDigital 4 characters alphanumericDigital 4 characters alphanumericConnector3-PinXLR (In and Out)3-PinXLR (In and Out)3-PinXLR (In and Out)NO.of LED12*3-IN-1W RGB LEDS12*3W LEDS (4R/ 4B/ 4G)18*3W LEDS (6R/ 6B/ 6G)LED Life Time80000-100,000 hours80000-100,000 hours80000-100,000 hoursBeam Angle25°/30°25°/30°25°/30°Power Consumption45W45W65WLight Projecting Distance10-15M10-15M10-15MIP RatingOutdoor, IP 65Outdoor, IP 65Outdoor, IP 65Operating Temperature-20ºC+45ºC-20ºC+45ºC-20ºC+45ºCDimensionsL260*Ø200 mmL260*Ø200 mmL260*Ø200 mmWeight4.80KGS4.80KGS4.80KGSPacking DimensionL27*W27*H37 cmL27*W27*H37 cmL27*W27*H37 cmGross Weight5.00KGS5.00KGS5.00KGSCompatibility:1.  Color Range: 16.7 million  additive  RGB  colors; continuously  variable  intensity (256×256×256=16777216)2. Dimming 0-100%with regulated constant color control3.Strobe: 10 Flashed per second (any color)4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable5. 6channel Mode and 3channel Mode would change each other in every light6. 6CH Mode DMX ValueCH 1 _ General dimmer   (1-255, Dimmer, from dart to light)CH 2_ Red          (1-255, Dimmer, from dart to light)CH 3 _ Green        (1-255, Dimmer, from dart to light)CH 4_Blue           (1-255, Dimmer, from dart to light)CH 5_ Strobe & Color change/ color gradual change openCH 6 _Strobe & Color change& color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)7. 3CH Mode DMX ValueCH 1_ Red         (1-255, Dimmer, from dart to light)CH 2 _ Green       (1-255, Dimmer, from dart to light)CH 3_Blue          (1-255, Dimmer, from dart to light)8.Control modes0: sound activity mode1. DMX control mode2. Adjusting the color manual3. Adjusting the brightness manual4. Adjusting the strobe manual5. Adjusting the strobe speed manual6. Master-slave control mode, as the master7. Sound activity synchronization mode8. Adjustingcolor's gradual change manual9.Adjustinggradual change's speedEach Package Included:1 * LED 1005/LED 1005I/LED 1005II LED PAR 64 with
Signal Cable :3-PinXLR DMX In and Out + Water Power cable: Power Cable screw water proof connectors in and out (2ftcable)1*Power cable: 3 Pin plug and screw water proof connector on other side. (5ft = 1.5m)1 * User Manual2* pyrocondensation.cannula (0.66ft = 20cm)1* Waterproof connector's cover for Power cable
Package
LED Waterproof PAR 64 / LED Wall Washer Light LED Stage Light
