Ce RoHS 2019 Supermarket Full PC Cover 20W LED Tri-Proof Light IP65 Triproof
Cixi Yuanhui Lighting Electric Co., Ltd.- Application:Parking Lot
- Type:Efficient-Mirror Tri-proof Light
- Feature:Anti-corrosion, Dust-Proof, Waterproof, Triproof
- Light Body Material:Plastic
- Transport Package:Innerbox&Carton
- Specification:Product label 700,1000,1300,1600*60*60mm
Base Info
- Model NO.:YL10
- Trademark:Default is Yuanhui Can be customized
- Origin:Ningbo, China
- HS Code:9405409000
- Production Capacity:10000PCS,Month
Description
1.Technical Paramenters (Test Conditions:25ºC/55-%60%Humidity)
Item Code
YL10-20W-
700(A)
YL10-24W-
1000(A)
YL10-24W-
1300(A)
YL10-36W-
1300(A)
YL10-36W-
1600(A)
YL10-50W-
1600(A)
Power(W)+/-10%
20W
24W
24W
36W
36W
50W
Input Voltage/Frequency
AC 220-240V 50/60Hz
Installation
Easy and quick to install under celling or on surface
Housing/Diffuser
PC material,could meet Ik08 and 850 GWT requirement
Driver
Osram / Philips / Tridonic / Chinese local brand
LED Brand
LG 2835 / EVERLIGHT 2835
CCT
2700-6500K (ANSI C78.377)
CRI
> 80
Light efficiency
125lm/W
5000K/Opal Diffuser
Light Output(+/- 3%)
2,500 lm
3,000 lm
3,000 lm
4,500 lm
4,500 lm
6,250 lm
Power factor
PF>0.9
Beam Angel
120°
IP Rating
IP65
Warranty
3 Year
Operating temp range
-20 to +35
Product Size (mm)
700*60*60
1000*60*60
1300*60*60
1300*60*60
1600*60*60
1600*60*60
Carton Size (mm)
735*280*210
1035*280*210
1335*210*210
1335*210*210
1635*210*145
1635*210*145
Q'ty/CTN (pcs)
12
12
9
9
6
6
Q1: Can I have a sample order for led light?
A1: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: What is the lead time?
A2: Samples need 3-5 working days, mass products need 7-10 days.
Q3: Do you have any MOQ limit for led light order?
A3: Low MOQ, 1pc for sample checking is available
Q4: How do you ship the goods and how long does it take to arrive?
A4: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5: How to proceed an order for led light?
A5: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q6: Is it OK to print my logo on led light product?
A6: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A7: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A8: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity.
For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
