12/18*18W Rgbwauv 6in1 LED PAR 64 / LED Wall Washer Light Waterproo IP 65
Guangzhou MS Lighting Co., Ltd.(China)- Type:PAR64
- Emitting Color:Full Range
- Power:216W,324W
- Waterproof:Waterproof
- IP Rating:IP65
- Life:80000h
Base Info
- Model NO.:LED 1008L,LED 1008M
- Electric Current Type:AC
- Input Voltage:110-220V
- Diffuser:Tempered Glass
- Shell Material:Aluminium Alloy
- LED Chips:CREE
- Certification:CE
- Color:Rgbwauv 6-in-1
- Transport Package:Carton,Flycase
- Specification:Dimensions: 31*31*37cm Weight: 8.50KGS
- Trademark:MSLighting
- Origin:Guangzhou, China
- HS Code:94054090
- Production Capacity:500PCS,Week
Description
Specification:Model LED 1008L LED 1008M NO. of LED 12*18W RGBWAUV 6-IN-1 MULTI-CHIP LED LAMP 18*18W RGBWAUV 6-IN-1 MULTI-CHIP LED LAMP Power Consumption 216W 324W DMX Channel 9CH/6CH Control panel Digital 4 characters alphanumeric Housing Color Black/White Operating voltage 100-230V AC Control Modes Direct DMX 512, Master/slave. Stand alone. Sound Activity Connector 3-PinXLR (In and Out) LED Life Time 80000-100, 000 hours Beam Angle 25° /30° Light Projecting Distance 50-150M IP Rating Waterproof IP 65 outdoor, Indoor Operating Temperature -20° c-+45° c Packing Dimension 31*31*37cm/ 62*62*39cm (4pcs) Gross Weight 8.50KGS /32.00kg(4pcs) Compatibility: 1. Color Range: 16.7 million additive RGBWAUV colors; continuously variable intensity (256× 256× 256=16777216) 2. Dimming 0-100%with regulated constant color control 3. Strobe: 10 Flashed per second (any color) 4. Function: it is max mix color, color change, flash, speed/luminance the adjustable 5. 9channel Mode and 6channel Mode would change each other in every light 6.9CH Mode DMX Value CH 1_General dimmer (1-255, from dart to light) CH 2_Red (1-255, Dimmer, from dart to light) CH 3_Green (1-255, Dimmer, from dart to light) CH 4_Blue (1-255, Dimmer, from dart to light) CH 5_White (1-255, Dimmer, from dart to light) CH 6_AMBER (1-255, Dimmer, from dart to light) CH 7_UV (1-255, Dimmer, from dart to light) CH 8_Strobe & Color change/ color gradual change open CH 9_Strobe & Color change& color gradual change' s speed adjustment (1-255, Speed adjustment, from slow to fast) 7.6CH Mode DMX Value CH 1_Red (1-255, Dimmer, from dart to light) CH 2_Green (1-255, Dimmer, from dart to light) CH 3_Blue (1-255, Dimmer, from dart to light) CH 4_White/Amber (1-255, Dimmer, from dart to light) CH 5_AMBER (1-255, Dimmer, from dart to light) CH 6_UV (1-255, Dimmer, from dart to light) 8. Control modes 0: sound activity mode 1. DMX control mode 2. Adjusting the color manual 3. Adjusting the brightness manual 4. Adjusting the strobe manual 5. Adjusting the strobe speed manual 6. Master-slave control mode, as the master 7. Sound activity synchronization mode 8. Adjustingcolor' s gradual change manual 9. Adjustinggradual change' s speed
