7*3in1 RGB Tricolor LED Plat PAR Light /Stage Light LED PAR Light
Guangzhou MS Lighting Co., Ltd.(China)- Type:PAR64
- Emitting Color:Full Range
- Power:30W
- Waterproof:Not Waterproof
- IP Rating:IP20
- Life:50000h
Base Info
- Model NO.:LED 114B
- Electric Current Type:AC
- Input Voltage:220V
- Shell Material:Aluminium Alloy
- LED Chips:CREE
- Certification:CE, EMC, LVD
- Color:RGB 3-in-1
- Transport Package:Carton,Flycase
- Specification:Dimensions: 30*30*19cm Weight: 3.50kg
- Trademark:MSLighting
- Origin:Guangzhou, China
- HS Code:94054090
- Production Capacity:500PCS,Week
Description
Specification:Model LED 114B (7*3-IN-1 RGB) DMX Channel 6CH Control panel Digital 4 characters alphanumeric Housing Color Black Operating voltage 100-230V AC Control Modes Direct DMX 512, Master/slave. Stand alone. Sound Activity Connector 3-PinXLR (In and Out) NO.of LED 7*3-IN-1 RGB LED LAMP LED Life Time 80000-100,000 hours Beam Angle 25°/30° Power Consumption 20W Light Projecting Distance 10-15M IP Rating Indoor Operating Temperature -20°c-+45°c Packing Dimension 30*30*19cm/ 54*31*62cm (6pcs) Gross Weight 3.50KGS /18.00kg(6pcs) Compatibility: 1. Color Range: 16.7 million additive RGB colors; continuously variable intensity (256×256×256=16777216) 2. Dimming 0-100%with regulated constant color control 3.Strobe: 10 Flashed per second (any color) 4. Function: it is max mix color, color change, flash, speed/luminance the adjustable 5. 6CH Mode DMX Value CH 1_Red (1-255, Dimmer, from dart to light) CH 2_Green (1-255, Dimmer, from dart to light) CH 3_Blue (1-255, Dimmer, from dart to light) CH 4_RGB Mixing (1-255, Dimmer, from dart to light) CH 5_Strobe (1-255, from slow to fast) CH 6_Dimmer 6.Thermal
Maximum ambient temperature: 40° Maximum housing temperature: 60°
