12/18*18W Rgbwauv 6in1 LED PAR Can / LED Wall Washer Light
Guangzhou MS Lighting Co., Ltd.(China)- Type:PAR64
- Emitting Color:Full Range
- Power:216W,324W
- Waterproof:Not Waterproof
- IP Rating:IP20
- Life:80000h
Base Info
- Model NO.:LED 1004N,LED 1004O
- Electric Current Type:AC
- Input Voltage:110-220V
- Diffuser:Polycarbonate
- Shell Material:Aluminium Alloy
- LED Chips:CREE
- Certification:CE
- Color:Rgbwauv 6-in-1
- Transport Package:Carton,Flycase
- Specification:Dimensions: 50*27*27cm Weight: 9.00kg
- Trademark:MSLighting
- Origin:Guangzhou, China
- HS Code:94054090
- Production Capacity:500PCS,Week
Description
Specification:Model LED 1004O (18*18W RGBWAUV 6-IN-1 MULTI-CHIP LED) LED 1004O (18*18W RGBWAUV 6-IN-1 MULTI-CHIP LED) DMX Channel 9CH/6CH 9CH/6CH Control panel Digital 4 characters alphanumeric Digital 4 characters alphanumeric Housing Color Sliver/Black Sliver/Black Operating voltage 100-230V AC 100-230V AC Control Modes Direct DMX 512, Master/slave. Stand alone. Sound Activity Direct DMX 512, Master/slave. Stand alone. Sound Activity Connector 3-PinXLR (In and Out) 3-PinXLR (In and Out) NO. of LED 12*18W RGBWAIV 6-IN-1 MULTI-CHIP LE D LAMP 18*18W RGBWAIV 6-IN-1 MULTI-CHIP LE D LAMP LED Life Time 80000-100, 000 hours 80000-100, 000 hours Beam Angle 25° /30° 25° /30° Power Consumption 216W 324W Light Projecting Distance 25-200M 25-230M IP Rating Indoor Indoor Operating Temperature -20° c-+45° c -20° c-+45° c Packing Dimension 27*27*50cm/ 82*56*54cm (6pcs) 27*27*50cm/ 82*56*54cm (6pcs) Gross Weight 4.80KGS /28.00kg(6pcs) 4.80KGS /28.00kg(6pcs) Compatibility: 1. Color Range: 16.7 million additive RGBWA colors; continuously variable intensity (256× 256× 256=16777216) 2. Dimming 0-100%with regulated constant color control 3. Strobe: 10 Flashed per second (any color) 4. Function: it is max mix color, color change, flash, speed/luminance the adjustable 5.9channel Mode and 6channel Mode would change each other in every light 6.9CH Mode DMX Value CH 1_ General dimmer (1-255, from dart to light) CH 2_ Red (1-255, Dimmer, from dart to light) CH 3_ Green (1-255, Dimmer, from dart to light) CH 4_ Blue (1-255, Dimmer, from dart to light) CH 5_ White (1-255, Dimmer, from dart to light) CH 6_ AMBER (1-255, Dimmer, from dart to light) CH 7_ UV (1-255, Dimmer, from dart to light) CH 8_ Strobe & Color change/ color gradual change open CH 9_ Strobe & Color change& color gradual change' s speed adjustment (1-255, Speed adjustment, from slow to fast) 7.6CH Mode DMX Value CH 1_ Red (1-255, Dimmer, from dart to light) CH 2_ Green (1-255, Dimmer, from dart to light) CH 3_ Blue (1-255, Dimmer, from dart to light) CH 4_ White/Amber (1-255, Dimmer, from dart to light) CH 5_ AMBER (1-255, Dimmer, from dart to light) CH 6_ UV (1-255, Dimmer, from dart to light) 8. Control modes 0: sound activity mode 1. DMX control mode 2. Adjusting the color manual 3. Adjusting the brightness manual 4. Adjusting the strobe manual 5. Adjusting the strobe speed manual 6. Master-slave control mode, as the master 7. Sound activity synchronization mode 8. Adjustingcolor' s gradual change manual 9. Adjustinggradual change' s speed
