12/18*18W Rgbwauv 6in1 Multi-Color LED PAR 64s
Guangzhou MS Lighting Co., Ltd.(China)- Type:PAR64
- Emitting Color:Full Range
- Power:216W,324W
- Waterproof:Not Waterproof
- IP Rating:IP20
- Life:80000h
Base Info
- Model NO.:LED 1002N,LED 1002O
- Electric Current Type:AC
- Input Voltage:220V
- Diffuser:Tempered Glass
- Shell Material:Aluminium Alloy
- LED Chips:CREE
- Certification:CE, EMC, LVD
- Color:Rgbwauv 6in1
- Transport Package:Carton,Flycase
- Specification:255*255*365mm
- Trademark:MS Lighting
- Origin:Guangzhou, China
- HS Code:94054090
- Production Capacity:500PCS,Week
Description
Specification:Model LED 1002N (12*18W RGBWAUV 6IN1 ) LED 1002O (12*18W RGBWAUV 6IN1) DMX Channel 9CH/6CH 9CH/6CH Control panel Digital 4 characters alphanumeric Digital 4 characters alphanumeric Housing Material Aluminum (Short/Long) Aluminum (Short/Long) Housing Color Black/Silver Black/Silver Aperture Cover Aluminum Aluminum Operating voltage 90-254V AC 90-254V AC LED current 680mA 680mA Control Modes Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization Direct DMX 512, Master/slave. Stand alone. Sound Activity, Sound activity synchronization Connector 3-PinXLR (In and Out) 3-PinXLR (In and Out) NO.of LED 12*18W RGBWAUV 6IN1 Multi-Color 18*18W RGBWAUV 6IN1 Multi-Color LED Life Time 80000-100,000 hours 80000-100,000 hours Beam Angle 25°/30° 25°/30° Power Consumption 216W 324W Light Projecting Distance 50-300M 50-400M IP Rating Indoor Indoor Operating Temperature -20 ºC +45 ºC -20 ºC +45 ºC Dimensions L260xØ195 mm(Short), L385xØ195 mm(Long) L260xØ195 mm(Short), L385xØ195 mm(Long) Weight 2.50KGS/3.00kgs 2.50KGS/3.00kgs Packing Dimension 255*255*365mm (Short) 255*255*465mm (Long) 255*255*365mm (Short) 255*255*465mm (Long) Gross Weight 3.00KGS/3.50kgs 3.00KGS/3.50kgs Compatibility: 1. Color Range : 16.7 million additive RGBWAUV colors; continuously variable intensity (256×256×256=16777216) 2. Dimming 0-100%with regulated constant color control 3.Strobe: 10 Flashed per second (any color) 4. Function: it is max mix color, color change, color's gradual change, flash, speed/luminance the adjustable and Save function. 5. 9channel Mode and 6channel Mode would change each other in every light 6. 9CH Mode DMX ValueCH 1_ General dimmer (1-255, from dart to light) CH 2_ Red (1-255, Dimmer, from dart to light) CH 3_ Green (1-255, Dimmer, from dart to light) CH 4_ Blue (1-255, Dimmer, from dart to light) CH 5_ White (1-255, Dimmer, from dart to light) CH 6_ Ambert (1-255, Dimmer, from dart to light) CH 7_ UV (1-255, Dimmer, from dart to light) CH 8_ Strobe & Color change/ color gradual change open CH 9_ Strobe & Color change& color gradual change' s speed adjustment (1-255, Speed adjustment, from slow to fast) 7. 6CH Mode DMX Value CH 1_ Red (1-255, Dimmer, from dart to light) CH 2_ Green (1-255, Dimmer, from dart to light) CH 3_ Blue (1-255, Dimmer, from dart to light) CH 4_ White (1-255, Dimmer, from dart to light) CH 5_ Ambert (1-255, Dimmer, from dart to light) CH 6_ UV (1-255, Dimmer, from dart to light) 8. Control modes 0: sound activity mode 1. DMX control mode 2. Adjusting the color manual 3. Adjusting the brightness manual 4. Adjusting the strobe manual 5. Adjusting the strobe speed manual 6. Master-slave control mode, as the master 7. Sound activity synchronization mode 8, Adjustingcolor' s gradual change manual 9. Adjustinggradual change' s speed. Each Package Included: 1 *LED par 64 Light with
Signal Cable: 3-PinXLR DMX In and Out + Water Power cable: Power Cable screw water proof connectors in and out (2ft cable) 1 * User Manual 1*Power cable: 3 Pin plug and screw water proof connector on other side. (2ft cable) 2* pyrocondensation. cannula (0.66ft = 20cm) 1* Waterproof connector' s cover for Power cable
FAQ1. MOQ:
Generally if you choose the different products,our minimum order qty.also will be different.
2. Payment:
Actually, payment would be preferred,We accept by T/T (Transfer / Payment), Western Union/Money gram, Pay pal, Cash,L/C...and so on.
3. Delivery time:
The goods need 2-3 days to be made after receive deposit.
4. Why choose us?
a. We are China Leading manufacturer. We are confident that with our products Quick delivery time, excellent quality and comprehensive superior service we can give our customers complete satisfaction.
b.100% QC inspection before shipping.
c. OEM is available.
After service1.24 months warranty
2. If there is a problem with the product, please contact us and sent us the pictures or video for analyzing.Then we will guide you to fix it and provide the replacement parts for free if needed.Our service1. Reply your inquiry within 24 working hours.
2. Well-trained, experienced staffs answer all your questions.
3. OEM&ODM service.
4. Special discount are offered based on order quantity.
5. Exclusive and unique solution can be provided to our customers by our well-trained and professional engineers and staffs.
6. Your sales area, design and all your private information will be protectedContact usMS LIGHTING CO.,LTD
Gold Member of ALIBABA,MADE IN CHINA,SGS Audited Supplier (SGS No.:QIP-ASR141102)
Mobil: 008613246884800
Web.: mslighting.en.made-in-china.com
